Product technical indicators
Model | SH-AnJ-0208 |
Antenna form | Pyramid Horn |
Frequency Range | 2GHz~8GHz |
Standing wave | ≤2.0 |
Polarization | Single linear polarization |
Beam width | ≥45° |
Gain | 8～12dB |
Interface form | SMA-50K |
Oral size | 138.27×168.38mm |
Weight | ≤1.2kg |
Surface treatment | Conductive oxidation |
Operating temperature | -40~70℃ |
Storage temperature | -55~80℃ |
Product specification drawing
