Description
This product is specially designed for high-end RF scenarios such as phased array radar, LEO satellite communication, EW data link, and high-precision navigation systems, enabling efficient RF signal transceiving and beam steering, supporting multi-channel array integration, and meeting the stringent reliability requirements of Industrial, aerospace, and industrial-grade communications.
Specification
| Operating Frequency | 32～37GHz |
| Transmit Saturated Power | 26.5dBm |
| Transmit Power Gain | 25dB |
| Transmit Efficiency | 20% |
| Receive Noise Figure | 4.5dB |
| Receive Small Signal Gain (Single Channel) | 25dB |
| Receive Input P-1 | -30dBm |
| Power Supply Voltage | +5V, -5V, +3.3V |
| SIP Size | 10.8mm×9.5mm×2.25mm (Excluding Ball) |
| Others | 6-bit phase shift, 6-bit attenuation |
Ka-band Series SIP Transceiver Module Products
