Description
This product is specially designed for high-end RF scenarios such as phased array radar, LEO satellite communication, EW data link, and high-precision navigation systems, enabling efficient RF signal transceiving and beam steering, supporting multi-channel array integration, and meeting the stringent reliability requirements of Industrial, aerospace, and industrial-grade communications.
Specification
service frequency | 14～18GHz |
emission saturation power | 27dBm |
transmission power gain | 24dB |
emission efficiency | 25% |
received noise figure | 3.0dB |
Receive small signal gain (single channel) | 20dB |
Receive input P-1 | -30dBm |
Power Supply Voltage | +5V、-5V、 +3.3V |
SIP size | 12mm×12mm×2.5mm (excluding the sphere) |
other | 6 displacement phases, 6 attenuation periods |
Ku-band Series SIP Transceiver Module Products
